Genesis G70 / Kia Stinger Oil Catch Can Kit
Direct-Fit PCV-Side Catch Can System
The PNPC Oil Catch Can Kit provides a clean, direct-fit PCV-side solution for the Genesis G70 and Kia Stinger. It helps capture oil mist, moisture, and other crankcase vapors before they return to the intake tract.
Turbocharged engines can send oil mist and moisture through the PCV system during normal operation. Over time, these contaminants can coat parts of the intake path. Therefore, adding a catch can provides a separation point where oil and moisture can collect before the remaining vapors continue through the PCV system.
This complete kit combines a serviceable billet 6061 aluminum catch can with vehicle-specific mounting, pre-sized hoses, fittings, installation hardware, and an easy-access dump valve included as standard.
PCV-Side Catch Can System
The kit installs on the PCV side of the crankcase ventilation system. As crankcase vapors travel toward the intake, the catch can routes them through its internal separation section.
Oil and moisture can then collect inside the can instead of continuing directly into the intake path. Meanwhile, the PCV system continues to operate through the catch can setup.
- PCV-side catch can configuration
- Helps capture oil mist and moisture
- Helps reduce oil entering the intake tract
- Billet 6061 aluminum construction
- Dump valve included for quick draining
- Vehicle-specific installation layout
- Pre-sized hoses for supported engine configurations
- Factory-style mounting location
- Serviceable catch can design
Billet 6061 Aluminum Catch Can
The catch can uses billet 6061 aluminum construction for a durable, compact design that fits cleanly in the engine bay.
The can also features an internal separation or filter section that helps separate suspended oil and moisture from the crankcase vapors passing through it.
In addition, the catch can has a serviceable design, allowing you to open and inspect it when needed.
Dump Valve Included
A dump valve is included with every kit for quick and convenient draining during routine maintenance. You do not need to purchase the valve separately.
Instead of removing the entire catch can whenever fluid collects, the dump valve provides an easier way to drain the collected oil and moisture.
Vehicle-Specific Installation
Rather than using a universal mounting setup, the kit includes the components needed for the supported Genesis G70 and Kia Stinger applications.
- Vehicle-specific mounting bracket
- Pre-cut PCV hoses
- Required fittings
- Hose clamps
- Mounting hardware
The bracket uses factory-style mounting points for a clean installation. As a result, a standard installation normally does not require drilling new mounting holes into the chassis.
Genesis G70 Fitment
- Vehicle: Genesis G70
- Years: 2019+
- Engines: 2.0T, 2.5T and 3.3T gasoline engines that match the available product options
Kia Stinger Fitment
- Vehicle: Kia Stinger
- Years: 2018-2023
- Engines: 2.0T, 2.5T and 3.3T gasoline engines that match the available product options
What’s Included
- Billet 6061 aluminum oil catch can
- Internal separation / filter section
- Easy-access dump valve
- Vehicle-specific mounting bracket
- Pre-cut PCV hoses for the selected application
- Required fittings
- Hose clamps
- Installation hardware
Installation
Installation typically takes approximately 15 to 30 minutes with common hand tools.
During installation, you will disconnect the applicable PCV hose and route the PCV circuit through the catch can. Then, mount the can using the supplied bracket and connect the included hoses and fittings.
- Estimated installation time: 15-30 minutes
- Difficulty: Moderate
- No ECU tuning required
- No permanent engine modifications required for a standard installation
- No chassis drilling normally required
Catch Can Maintenance
An oil catch can requires periodic inspection and draining. Fortunately, the included dump valve makes this process quick and straightforward.
How quickly the can fills depends on the engine, vehicle use, modifications, climate, and driving conditions. Therefore, check the catch can frequently after the initial installation until you learn how quickly your specific vehicle collects fluid.
After establishing a normal collection rate, you can create a regular inspection and drain interval for your vehicle.
Why Install a PCV Catch Can?
The factory PCV system routes crankcase vapors back into the intake system. However, those vapors can contain suspended oil and moisture.
The catch can adds a separation point in that path. Therefore, some of the oil and moisture can collect inside the can before the remaining vapors continue through the PCV system.
The primary purpose of this kit is not to create additional horsepower. Instead, it focuses on reducing the amount of oil and moisture that travels through the intake path over time.
Fitment FAQ
Does this fit the Genesis G70?
Yes. The kit supports 2019+ Genesis G70 applications with the 2.0T, 2.5T, and 3.3T engines that match the available product options.
Does this fit the Kia Stinger?
Yes. The kit supports 2018-2023 Kia Stinger applications with the 2.0T, 2.5T, and 3.3T engines that match the available product options.
Does this kit work with the 2.0T, 2.5T and 3.3T?
Yes. Select the correct vehicle and engine configuration when ordering so you receive the correct setup for your application.
Installation & Maintenance FAQ
Do I need a tune after installing the catch can?
No. The catch can does not require ECU tuning by itself. It routes PCV vapors through the catch can before they continue through the intake system.
Does the catch can include a dump valve?
Yes. A dump valve is included with every kit for quick and convenient draining. You do not need to purchase the valve separately.
How often should I drain the catch can?
There is no single interval that applies to every vehicle. Check the can frequently after installation to determine how quickly your vehicle collects oil and moisture. Then, establish a regular drain interval based on your results.
Do I need to remove the catch can to drain it?
No. The included dump valve provides a convenient way to drain collected oil and moisture without removing the entire catch can for routine draining.
Do I need to drill holes to install the bracket?
A standard installation normally uses factory-style mounting points, so you should not need to drill new mounting holes into the chassis.
Can I open the catch can for inspection?
Yes. The catch can has a serviceable design, allowing you to open and inspect it when needed.
Performance & Use FAQ
Will I gain horsepower from installing a catch can?
The catch can is not designed as a peak-horsepower modification. Instead, its main purpose is to help reduce the amount of oil and moisture that returns to the intake path through the PCV system.
Is a catch can useful on a tuned car?
Yes. A PCV-side catch can can be useful on both stock and modified vehicles. However, the amount of fluid collected will vary based on the engine, modifications, driving conditions, and vehicle use.
Does the catch can replace the factory PCV system?
No. The catch can works within the PCV routing. It does not replace the vehicle’s entire crankcase ventilation system.
Is this kit emissions compliant?
Emissions and vehicle-modification requirements vary by location. This product is sold for off-road and track use only. The vehicle owner is responsible for checking applicable local laws and inspection requirements.
